ESSOR produces a full range of worm and wheel components, individually or as matched sets, engineered to your drawings and performance requirements. Explore our Split Worms and Wheels, Dual Lead Worms and Wheels, and ZC Worms and Wheels product lines below.
We manufacture cylindrical worms, single start worms, multi-start worms, and fully custom worm shafts for applications requiring specific lead angles, thread configurations, or gear ratios. Each worm shaft is precision ground and inspected to ensure consistent tooth form and dimensional accuracy. As a precision worm shaft manufacturer, ESSOR supports single-piece prototypes as well as production runs, machined from customer-specified materials and finished to tight tolerance. See our Dual Lead Worms for advanced multi-start configurations.
ESSOR manufactures bronze worm wheels and steel worm wheels with custom tooth profiles, in a wide range of modules and diameters. Worm wheels can be produced as solid components or with rim-and-hub construction, depending on load and cost requirements. As a worm wheel manufacturer, we offer custom worm wheel design and machining to match your worm shaft, gear ratio, and center distance specifications, including our ZC Worms and Wheels line.
We supply matched worm and wheel sets engineered together for optimized transmission performance, reduced backlash, and high efficiency. Because the worm and wheel in each set are cut and lapped as a pair, ESSOR worm gear sets deliver smoother meshing, quieter operation, and longer service life than mismatched components. As a worm gear set manufacturer, ESSOR can supply standard center distances and ratios or design a fully custom precision worm gear set — see our Split Worms and Wheels for a specialized set configuration.
ESSOR's worm and wheel production covers:
CNC turning for worm shaft and wheel blank machining
CNC milling for housings, mounting features, and custom geometries
Gear cutting (hobbing/generating) for precise worm and wheel tooth forms
Grinding of worm threads and critical diameters for tight tolerance and surface finish
Heat treatment to achieve required hardness and wear resistance
Surface finishing, including plating and coating options, for corrosion resistance and appearance
This complete precision machining process allows ESSOR to control every stage of worm gear manufacturing in-house, ensuring consistency between prototype and production parts.
Every batch of worms and wheels is verified through:
Dimensional inspection of critical diameters, lead, and center distance
Tooth profile inspection using gear measuring instruments to confirm profile, lead, and pitch accuracy
Backlash control to meet specified transmission accuracy requirements
Surface roughness testing on worm threads and wheel tooth flanks
This inspection process is what allows ESSOR to consistently deliver high precision worm gears. Learn more about our inspection process on the Measurement page.
Material selection affects load capacity, wear resistance, efficiency, and cost. ESSOR machines worms and wheels from a range of materials based on the application:
| Component | Common Materials | Key Properties |
|---|---|---|
| Worm Shaft | Alloy steel (e.g. 20CrMnTi, 40Cr), carbon steel, stainless steel | High strength, hardened and ground threads, good wear resistance |
| Worm Wheel — Tin Bronze | Tin bronze (e.g. ZCuSn10P1 / CuSn12) | Excellent sliding and anti-friction properties, high load capacity, well suited for continuous duty and higher sliding speeds |
| Worm Wheel — Aluminum Bronze | Aluminum bronze (e.g. ZCuAl10Fe3 / CuAl10Ni) | Higher strength and wear resistance than tin bronze, good corrosion resistance, suited for heavier loads and lower speeds |
| Worm Shaft (special applications) | Stainless steel (304 / 316) | Corrosion resistance for washdown or outdoor use |
ESSOR worm wheels are manufactured in aluminum bronze and tin bronze — the two bronze alloys we use for worm gearing — selected based on the load, speed, and duty cycle of each application, and paired with a hardened and ground steel worm shaft for optimal sliding contact and service life.
ESSOR provides full OEM production of custom worms and wheels, built to customer drawings, samples, or performance specifications. Visit our dedicated Customization page for details, or explore our broader Custom Solutions. Our custom worm gear manufacturing service covers:
OEM production under customer specifications and branding
Custom dimensions, including non-standard diameters, lengths, and center distances
Customized modules and gear ratios to match your gearbox or drive design
Drawings accepted — 2D/3D CAD files or physical samples for reverse engineering
Prototype production for design validation before committing to volume
Mass production with consistent quality across large order quantities
Whether you need a single custom worm gear manufacturer for a one-off replacement part or an ongoing OEM worm gear manufacturer partner for a product line, ESSOR's engineering and production teams can support your project from drawing to delivery.
ESSOR manufactures worms and wheels across a broad range of sizes and precision grades. Typical specification ranges include:
| Parameter | Typical Range |
|---|---|
| Module (m) | 0.5 – 10 mm |
| Number of starts | 1 – 4 |
| Center distance | 20 – 300 mm |
| Worm outer diameter | 10 – 150 mm |
| Worm wheel outer diameter | 20 – 500 mm |
| Gear ratio | 5:1 – 100:1 |
| Precision grade | DIN 3 – DIN 8 (per DIN 3974/3975) |
| Surface roughness | Ra 0.4 – 1.6 μm (ground threads) |
ESSOR's precision worms and wheels are used across a wide range of industries requiring reliable, high-ratio, right-angle power transmission:
Industrial Automation — precision motion control in automated production lines
Robotics — compact, self-locking drives for joint and axis positioning
Solar Tracking Systems — durable, weather-resistant drives for single- and dual-axis solar trackers, see our Azimuth Drive for Concentrated Solar Power System
Valve Actuators — precise, self-locking actuation for industrial valve control
CNC Machines — high-accuracy indexing for CNC rotary tables and machine tool positioning, see our Worm Gearboxes for Tool Magazine
Pumps — reliable gear reduction for pump drive systems
What are worms and wheels used for?
Worms and wheels are used to transmit power and motion at a right angle while achieving high gear reduction ratios in a single stage. Common applications include industrial automation, robotics, valve actuators, CNC rotary tables, solar tracking systems, and pump drives, wherever compact, high-ratio, and often self-locking transmission is required.
Can you manufacture custom worms and wheels?
Yes. ESSOR manufactures custom worms and wheels based on customer drawings, samples, or performance specifications, including custom modules, dimensions, and gear ratios, from prototype quantities through mass production. See our Customization page for more.
What materials are used for worm wheels?
ESSOR manufactures worm wheels in aluminum bronze and tin bronze. Tin bronze offers excellent sliding properties and is well suited to continuous duty at higher speeds, while aluminum bronze offers greater strength and wear resistance for heavier loads. Both are paired with a hardened, ground steel worm shaft.
Do you provide OEM worm gear manufacturing?
Yes. ESSOR is an OEM worm gear manufacturer, producing worms, wheels, and matched worm gear sets to customer specifications, including private-label and branded production for gearbox and equipment manufacturers.
What information is required for a custom worm gear quotation?
To provide an accurate quotation, we typically need: 2D/3D drawings or a physical sample, module and number of starts, center distance and gear ratio, material requirements, precision grade/backlash tolerance, and expected order quantity. If exact drawings aren't available yet, our engineering team can also assist with design based on your application requirements — contact us to get started.
Need precision worms and wheels for your application?
Send us your drawings or requirements and our engineering team will respond with a quotation.
